Revenge

made for competition,
made to race,
made for REVENGE

Take to the competitive trails atop the fastest aluminum hardtail ever made under the Lee Cougan brand. Ultra performance inspired geometry matches with fine construction methods and serious componentry to make for a race-ready companion built to take your further, faster. Welded from the finest grade 6061 aluminum, the Revenge frame is rigid and reactive enough to ensure the most powerful riders and efficient power transfer, thus allowing them to save energy for that ever important sprint to the finish.

The design

Following a design

Following a design input that derives from its top tier XC siblings, the Revenge incorporates a stiff and rigid Boost 148mm rear triangle to ensure snappy and agile changes in pace and direction.

Frontend

Along the same lines the front end incorporates a similar open head tube angle in order to overcome insidious obstacles with relative ease.

Groupset

SRAM SX EAGLE

1×12 speed, 32T cranck boost, Shimano MT401 Hydraulic disc brakes, 180mm rotors, PG1210 rear cassette 11-50T

Suspension

MANITOU MACHETE

The Machete is purpose-built for slicing trails, with Kwik Toggle compression damping inspired by our renowned Absolute+ technology. Kwik Toggle acheives on/off lockout simplicity in a lightweight, practical package.

Wheels

WOZ 25

WOZ 25 mm Rim, Boost, Sealed Bearings

Geometry

Every good bike fit starts with choosing the correct frame size for you. This will allow you to benefit best of the bike’s performance and comfort for an efficient riding position.

	XS	S	M	L
Seat tube (ST)	390 mm	430 mm	470 mm	500 mm
Top tube (TT)	565 mm	595 mm	615 mm	630 mm
Head tube (HT)	107 mm	107 mm	107 mm	107 mm
Chain stay (CS)	440 mm	440 mm	440 mm	440 mm
Head tube angle (HA)	70°	70°	70°	70°
Seat tube angle (SA)	72.7°	72.7°	72.7°	72.7°
Front center (FC)	633 mm	663 mm	683 mm	698 mm
